City of Elgin - O’Hare Western Bypass
Researched existing ROW plats, subdivision plats and PLSS monument records of nearly 1,000 parcels. Performed existing ROW survey of Elgin – O’Hare, Thorndale, I-294, I-90 & York Road, Mount Prospect Road, York Road, and West O’Hare boundary through West O’Hare loop area. Performed PLSS survey that resulted in the creation of a base .dgn file of existing ROW, PLSS lines, O’Hare west boundary, and import of alignments from corridor DSE. Recorded PLSS monument records at Cook and DuPage recorder of deeds offices.
Prepared a parcel GIS database of the existing ROW parcels that provide digital access to field notes, monument records, existing ROW plats, subdivision plats, base .dgn file, and parcel GIS in file depository available for download by ISTHA and design DSE’s for additional use by our appraisers and negotiators for the land acquisition phase of the project.
Additional work orders included the management of 60 “high value” appraisals and negotiations for the acquisition of properties for the Western Bypass along existing Thorndale Avenue. Reviewed over 700 Plats of Acquisition, Legal Descriptions and associated legal documents to ensure compliance with Illinois State Tollway requirements.
